Additional information
| Weight | 1.88 lbs |
|---|---|
| Dimensions | 4.50 × 8.25 × 6.25 in |
STXR480Y05N
STXR Type1 50kA 480Y/277V N-G Surge Protection Device
The Surge-Trap® surge protectors meet the requirements for UL1449 Fourth Edition and feature TPMOV® technology inside making them the safest product available. The STXH Series is suitable for any 120/240VAC split phase application. Its compact size, performance and reliability is especially ideal for HVAC applications and direct mounting to air condition disconnect switches. The STXR series is the perfect fit for branch panel and/or individual equipment protection with its small, compact design and line or load installation flexibility.
| Item | UPC/SCC | Width | Height | Depth | Weight | Sell Units Per |
|---|---|---|---|---|---|---|
| Unit | 0782001469986 | 8.25 | 6.25 | 4.50 | 1.88 | |
| Case | 70782001469985 | 22.50 | 10.75 | 14.50 | 16.60 | 8 |
| Master Case | 0 | 0.00 | 0.00 | 0.00 | 0.00 | 0 |
| Pallet | 0 | 0.00 | 0.00 | 0.00 | 0.00 | 0 |
| HS Code | Country Of Origin | NAFTA Preference Criterion | NAFTA Producer Index |
|---|---|---|---|
| 8535.40.0000 | Mexico | c | c |
